SPECIFICATION FOR 30’ x 30’ SHAMIANA, JODHPURI STYLE WATER PROOF TOP
SPECIFICATION: - SIZE & ACCESSORIES- 30 FT X 30 FT, SIDE HEIGHT 9 FT, MIDDLE HEIGHT 14 FT, WITH COMPLETE ACCESSORIES

STYLE - JODHPURI SAMIYANA WITH FRONT JHALLAR AND 1 PARDA OF 30 FT X 9 FT AND 2 PARDE OF 30 FT X 9 FT EACH.
TOP CLOTH TYPE - WATER PROOF RIB STOP POLYCOTTON CANVAS CLOTH 360 GSM

DESCRIPTION OF PARDA - INNER SIDE CLOTH WILL BE BLUE AND OFF WHITE POLYCOTTON CLOTH WITH 20 INCH EMBROIDERED LOGO OF DEPARTMENT AND OUTER SIDE CLOTH WILL BE BLUE & OFF WHITE POLYCOTTON CLOTH AND ALSO FRONT JHALLAR WITH EMBROIDERY CREST OF DEPARTMENT.
ITEMS INCLUDED IN THE JODHPURI SHAMIANA SET:
1 no. Top – Waterproof rib stop poly cotton 30 ft x 30 ft
1 no. ceiling - Print poly cotton cloth 30 ft x 30 ft
1 no. double centre wall -  poly cotton cloth 30 ft x 9 ft with 3 nos. 20” embroidered crest/logo of department on inner side and off white on outer side
2 nos. double side wall - 2 side with double poly cotton cloth 30 ft x 9 ft with 6 nos. 20” embroidered crest/logo of department on inner side dual tone(blue and off white) strip pattern on outer side
30’ x 1.5’ 15 nos. jhalar on top front with 8 crest/logo of department of 8 inch
3 nos. front parda with frill design 10 ft x 9 ft – lycra cloth
2 nos. front parda with frill design 5 ft x 9 ft – lycra cloth
12 nos. pole covers 9 ft. of poly cotton cloth
12 nos. standing poles with base plate + V stopping/u-clip – 2 inch dia apprx.
13 nos. ridge poles 10 ft. – 2 inch dia apprx.
16 nos. taper pole 10 ft – 1.25 inch dia apprx.

WEIGHT OF THE ENTIRE SET OF PIPES: 290 KG apprx.
